DisplayLink DL-7xxx Series

Product Family Overview

The DisplayLink DL-7xxx family is designed from the ground up for transport-agnostic connectivity, delivering a flexible platform for high-performance display and peripheral applications.

Supporting up to dual 8K at 60 Hz or quad 4K at 120 Hz, the DL-7xxx family includes 2.5 Gbps Ethernet, IoT connectivity, HDR10 support, dynamic splash screens, hostless graphics, and peripheral status reporting as standard. It is ideal for thin clients, docking stations, PCIe cards, and adapters.

Trusted by Dell, HP, StarTech, Plugable, Anker, Wavlink, OWC, i-Tec, MBeat, TobenONE, and many others, the DL-7xxx family enables partners to build scalable, future-ready products for evolving display and connectivity requirements.

Contact Synaptics Sales for further details.

Ultra-Low Latency Performance

Link-Aware Bandwidth Adaptation

DisplayLink Direct

USB or Ethernet Link

Feature / IC	Earlier DL-6xxx IC	DL-7200	DL-7400
Applications	-	Docking Station / Adapter Handset Cradle Meeting Video Bar Meeting Switcher / Hub / PC POS Display Embedded Panel Robotics Display Digital Signage Mini PC / Thin Clients	Docking Station / Adapter Handset Cradle Meeting Video Bar Meeting Switcher / Hub / PC POS Display Embedded Panel Robotics Display Digital Signage Mini PC / Thin Clients
Video Outputs	2	2	4
Maximum Resolution	1* 5K or 2* UHD	*1 8K or 2* UHD**	*2 8K or 4* UHD**
Ingress	USB3 5Gbps	USB3 10Gbps	USB3 10Gbps
Memory	External DRAM DDR3	External DRAM LPDDR4 / DDR4	External DRAM LPDDR4 / DDR4
LVDS	-	-	-
eDP	Integrated	Integrated	Integrated
Digital RGB	-	-	-
VGA	-	-	-
DVI	-	-	-
HDMI	Integrated v2.0	Integrated 2.0	Integrated 2.0
DP	Integrated v1.2	Integrated v1.4	Integrated v1.4
Codec	DL3	DL3	DL3
HDCP	Integrated	Integrated	Integrated
Ethernet	1Gbps	1Gbps / 2.5Gbps	1Gbps / 2.5Gbps
Audio	5.1 Channel	6 Channel	6 Channel
HDR	Standard	HDR10	HDR10
DDC/CI	Supported	Supported	Supported
DisplayLink Direct	Supported	Supported	Supported
Dock Status API	-	Supported	Supported
Splash Screens	-	Dynamic	Dynamic
Enterprise Features	GOP Modern Standby Wake On LAN PXE Boot MAPT	GOP Modern Standby Wake On LAN PXE Boot MAPT	GOP Modern Standby Wake On LAN PXE Boot MAPT

Certification

DisplayLink certified not only signifies that the product is enabled by one of our many award-winning chipsets, it also highlights that the design has been scrutinized and meets the stringent design needs to carry our certified brand mark. Buying products that carry the brand equally signifies to end users a level of uncompromisable compatibility, allowing products from multiple vendors to work seamlessly together. Building confidence, ensuring usability, enabling freedom of choice, plus our unequaled extensibility.
