Our highly-integrated Wi-Fi / Bluetooth single-chip SoC devices are fully compliant with the Bluetooth SIG and Wi-Fi Alliance specifications and certification requirements. The integration with internal PA and internal LNA offers the lowest BOM and best performance for broad applications. The well architected co-existence scheme delivers the best Wi-Fi and Bluetooth performance when operating in the same frequency band.


Family Part Number Wi-Fi Spec Band Radio Chains Bluetooth Spec 802.15.4 Status
Wi-Fi + Bluetooth + Thread/Zigbee SYN4382 Wi-Fi 6E 2.4GHz, 5GHz, 6GHz 2x2 RSDB (2x2+1x1) 5.3 Yes Active
Wi-Fi + Bluetooth + Thread/Zigbee SYN4381 Wi-Fi 6E 2.4GHz, 5GHz, 6GHz 1x1 5.3 Yes Active
Wi-Fi + Bluetooth SYN43711 Wi-Fi 6E 2.4GHz, 5GHz, 6GHz 1x1 5.3 Active
Wi-Fi + Bluetooth SYN4375 Wi-Fi 6 2.4GHz, 5GHz 2x2 RSDB 5.2 Active
Wi-Fi + Bluetooth SYN43756 Wi-Fi 6E 2.4GHz, 5GHz, 6GHz 2x2 5.3 Active
Wi-Fi + Bluetooth SYN43752 Wi-Fi 6 2.4GHz, 5GHz 2x2 5.2 Active
Wi-Fi + Bluetooth SYN43598 Wi-Fi 5 2.4GHz, 5GHz 2x2 5.2 Active
Wi-Fi + Bluetooth SYN43456 Wi-Fi 5 1x1 5.2 Active
Wi-Fi + Bluetooth SYN43438 Wi-Fi 4 5.x Not recommended for new products. Contact Sales for more info.
Wi-Fi + Bluetooth SYN43436 Wi-Fi 4 2.4GHz 1x1 5.2 Active
Wi-Fi + Bluetooth SYN430132 Wi-Fi 4 2.4GHz, 5GHz 1x1 LPC 5.2 Active
Bluetooth/BLE SYN20703 BT Only 5.2/LE Active

Synaptics Wi-Fi Sensing

Wi-Fi Sensing is a new method that allows Wi-Fi signals to be used to determine movement and sense people or animals but Synaptics approach takes this to a new level to even be able to detect a person completely motionless based on breathing. Applications for this include home security, automotive safety to ensure a baby or pet isn't left in a car and of course healthcare. Watch the video to learn more and get an overview on Wi-Fi Sensing, which is available on all Synaptics connectivity products from 2024 onwards.

SYN43711 Wi-Fi, Bluetooth SoC

  • High integration reduces footprint, cost, power, complexity, and time to market.
  • 2.4 GHz and 5 or 6 GHz bands simultaneously with up to 600 Mbps throughput.
  • Allows multiple concurrent Bluetooth connections and audio streams.
  • Advanced Wi-Fi/Bluetooth radio co-existence.
Learn More

Our world-class Global Navigation Satellite System (GNSS) SoC devices includes unmatched L1+L5 dual-frequency GPS technology for broad applications. Each of our products have an integrated sensor hub and on-chip PVT (process, voltage, temperature sensor)

Product Band Constellation LTE Coexistence Grid Tracking & Integrated Switching Regulator Support OS Power Consumption
SYN4778 L1 & L5 GPS,Glonass, Beidou, Galileo,QZSS, NAVIC New Generation
On-chip LTE Filter
Yes Android/RTOS 80% tracking power reduction compared to the previous generation
SYN47768 L1 & L5 GPS,Glonass, Beidou, Galileo,QZSS, NAVIC On-Chip LTE Filter N/A Android/RTOS Industry Leading
SYN47762 L1 GPS,Glonass, Beidou, Galileo,QZSS On-Chip LTE Filter N/A Android/RTOS Industry Leading

Our high-performance ULE solutions operate in an interference-free band and support secure, ultra-low-power, long-range wireless communications with high QoS and native support for two-way voice.
