Astra™ SL2610 产品系列
产品系列概述
The new Synaptics Astra SL2610 product line delivers exceptional performance and power efficiency for multimodal compute across IoT devices ranging from smart home appliances, wearables, and smart retail, to robotics, charging infrastructure, and industrial systems. With five pin compatible processor families, it is built for a wide range of AI-native compute solutions from battery-powered and passively cooled devices to high-performance industrial vision systems.
Experience the groundbreaking Synaptics Torq™ Edge AI platform – with the transformer – and CNN capable Torq T1 NPU together with the industry’s first production implementation of the Coral NPU from Google. This integrated architecture allows for dynamic support of new operators, future-proofing Edge AI IoT system design. Torq advances true AI developer freedom by means of a disruptive, an end-to-end compiler and runtime based on the open-source IREE/MLIR projects, supporting both standard and emerging model formats such as LiteRT, PyTorch, ONNX and JAX.
Built on a high-efficiency architecture powered by Arm® Cortex®-A55, Cortex-M52, and the Mali™ 3D GPU, the SL2610 processors advance the state of silicon, device, and system-level security, with features ranging from immutable root of trust to application crypto processing – making it well-positioned to address a fast-evolving threat landscape at the IoT AI device edge.
通过 Synaptics Torq 物联网边缘 AI 平台,体验真正的开发自由
博客
深受行业领导者信赖
模块图与功能特性
- SL2610 Key Feature
- Peripherals
- Memory Interface
- CPU
- AI Engines
- System Manager
- Secure Island
- Video/GFX
- Audio
产品特性
计算 & AI
- 单核/双核 Arm Cortex-A55 SoC 域
- Arm Cortex-M52(搭载 Helium)系统管理域
- 1 TOPS Transformer 支持 NPU
- Coral Open NPU(RISC-V ML 核心)
图形、音频 & 多媒体
- 3D GPU,Arm Mali-G31
- MIPI-DSI 与 CSI,支持 2160p30 和 HDR
- 3 路 TDM/I2S,16 通道,支持 8 个数字麦克风
- 硬件音频与摄像头静音功能
连接 & I/O
- 2 个 USB 2.0、2 个 SDIO 3.0、4 个 TWSI I2C、8 个 UART
- 5 个 SPI、2 个 xSPI、99 个 GPIO
- 12 位 ADC,可支持 12 个智能 PWM 模块(SM 域)
安全、内存&网络
- DDR4 / LPDDR4 / DDR3L 内存,支持内置 ECC
- PSA 认证:Level 3(RoT)、Level 2(产品)
- 安全启动、TRNG、RSA、AES、SHA、ECC、HASH
- 单/双 GbE RGMII,支持 Wake-on-LAN
- 1588 PTP 与 TSN,802.1 p/q VLAN 标签
Astra Machina SL2610 开发套件
Synaptics Astra Machina SL2600 系列开发套件可实现多模态 AI 原生 IoT 应用的快速原型开发。 其灵活的模块化设计支持核心计算模块、I/O 底板、集成 Wi-Fi / Bluetooth 的子卡、调试接口以及可编程 I/O, 满足复杂系统原型设计需求。评估系统兼容 Synaptics SL2619 SoC 系列,在 IoT 设备中实现前所未有的性能功耗比, 并通过基于 Yocto Linux 的统一开放软件环境提供支持。Machina SL2600 系列基于开源 Synaptics Torq™ 边缘 AI 平台构建, 集成 Coral Open NPU 子系统,可提供高效的多模态 AI 推理能力及灵活的边缘计算加速。
下载产品介绍 预约了解
技术文档

开启您的AI之旅
几分钟快速部署端侧AI
立即上手使用为 Synaptics Astra 处理器预优化的 AI 模型,探索更多可能性。借助一流的嵌入式 AI 工具,可将 PyTorch、ONNX 或 TensorFlow Lite 模型优化至设备端 AI 加速器,实现高效本地 AI 推理。
以易用性为核心设计
Astra Machina 是业内领先的 IoT 系统,集计算能力、边缘 AI 技术与连接性于一体,基于开放软件构建。模块化开发套件适用于 Astra SL 系列高性能 IoT 处理器,并集成 Synaptics 无线连接功能。
